Nocpix RICO 3 L35R 384x288 3x 35mm LRF Thermal Scope

NOCPIX RICO 3 L35R Thermal Weapon Sight

The NOCPIX RICO 3 L35R is part of NOCPIX's next-generation RICO 3 thermal weapon sight family. NOCPIX describes the platform as an integrated smart thermal shooting system that builds on the RICO 2 with advanced ballistic integration, enhanced laser-rangefinder capability and extended battery life. This RICO3 L35R configuration combines a 384x288 thermal sensor, 35 mm F/1.0 objective, 3X base magnification and an integrated 1,600-yard laser rangefinder in a magnesium, IP67-rated housing.

For hunters and shooters comparing thermal optics, the RICO 3 platform brings ranging, ballistic calculation, imaging, recording and connectivity into one optic. Review the specifications below and add the NOCPIX RICO 3 L35R to your cart at BattleHawk Armory when this model fits your needs.

Compact 35 mm Configuration with 3X Magnification

The L35R uses a 384x288, 12-micron thermal sensor, a 35 mm F/1.0 objective and 3X base magnification. NOCPIX lists a 1,990-yard detection range and a 7.5 x 5.7 field of view. Reality+ image processing and a 60 Hz refresh rate support the viewing experience, while up to 4X digital zoom gives the user additional image enlargement when needed.

At 28.89 ounces and 8.90 inches long, the L35R is the lightest model in the RICO 3 family. It retains the integrated 1,600-yard rangefinder, ballistic calculation, recording, 64 GB storage, app connectivity, 10-hour maximum operating time and 2560x2560 AMOLED display found throughout the family. This makes it a compact way to access the RICO 3 platform with a 384-class sensor and 35 mm optical configuration.

Integrated Rangefinding and Ballistic Support

An integrated laser rangefinder provides distance readings out to a listed 1,600 yards, while the onboard ballistic-calculation feature supports a more streamlined firing-solution workflow. The scope includes eight reticle types - seven static designs and one DIY option - plus multiple reticle colors for adapting the display to the selected thermal palette and background. Picture-in-picture mode can keep a magnified aiming area visible while preserving more of the surrounding scene.

Range and ballistic features are decision-support tools, not substitutes for positive target identification, a safe backstop or independently verified firearm and ammunition data. Enter and confirm the correct ballistic information, follow the current NOCPIX instructions and observe all applicable laws and safe-firearm practices.

Thermal Image, Display and Viewing Options

• Thermal resolution: 384x288 with 12-micron pixel size
• Thermal sensitivity: 15 mK or less
• Refresh rate: 60 Hz
• Image processing: Reality+ using the Nocpix 384 core
• Objective lens: 35 mm F/1.0
• Magnification: 3X base; 4X digital
• Field of view: 7.5 x 5.7
• Listed detection range: 1,990 yards
• Display: 1.03-inch AMOLED with 2560x2560 resolution
• Thermal palettes: White Hot, Black Hot, Red Hot, Rainbow, Violet, Crimson and Viridian
• Diopter adjustment: -5 to +5
• Eye relief: 60 mm

Recording, Connectivity and Power

The RICO 3 can capture video and still images, and it supports recoil-activated recording. Built-in 64 GB storage provides space for saved media, while wireless connectivity allows image and video transfer through the compatible app. A USB-C connection handles data and power functions. The power system uses USB-C and two NBP-8 lithium-ion batteries, with a listed maximum operating time of 10 hours. Startup is specified at less than 10 seconds, with instant operation available from standby.

Actual runtime, image quality, detection performance and recording capacity can vary with temperature, settings, zoom, wireless use, battery condition, atmospheric conditions and the size of the observed heat source. The thermal images shown by the manufacturer are illustrative, and real-world results may differ.

Mounting, Construction and Environmental Specifications

• Mounting system: Picatinny MIL-STD-1913 rail
• Housing: Magnesium
• Ingress protection: IP67
• Operating temperature: -4F to 122F
• Maximum recoil rating: 1,000 g/s, listed for .300 Win. Mag. and 7 mm Mag.
• Dimensions: 8.90 x 3.43 x 3.43 inches
• Weight: 28.89 oz
• Manufacturer warranty: 5 years

Confirm rail space, eye position and fastener torque before use. After mounting, verify zero and inspect the installation regularly. The maximum recoil listing does not replace the firearm, mount or ammunition manufacturer's requirements. NOCPIX products are distributed and supported in the United States by iRayUSA.

Choosing the L35R within the RICO 3 Family

The L35R and H35R share a 35 mm F/1.0 objective and a listed 1,990-yard detection range, but they are optimized differently. The L35R uses a 384x288 sensor, 3X base magnification, a 7.5 x 5.7 field of view and up to 4X digital zoom. The H35R uses a 640x512 sensor, 2X base magnification, a wider 12.6 x 10.1 field of view and up to 8X digital zoom. The L35R is slightly lighter. Those differences help shoppers choose between more base magnification and lower weight or the H35R's higher sensor resolution and wider viewing window.

Frequently Asked Questions

Does the NOCPIX RICO 3 L35R include a laser rangefinder?

Yes, an integrated laser rangefinder with a maximum range of 1,600 yards. Range performance can vary with target size, reflectivity, weather and environmental conditions.

Can the RICO 3 record thermal video?

Yes. The optic supports video, still-image capture and recoil-activated recording, with 64 GB of onboard storage and wireless image and video transfer through the compatible app.

How long does the battery system operate?

NOCPIX lists a maximum operating time of 10 hours using the USB-C and dual NBP-8 lithium-ion battery system. Actual runtime depends on settings, temperature, wireless use and battery condition.

Is the RICO 3 weather resistant?

The magnesium housing carries an IP67 ingress-protection rating and a listed operating-temperature range of -4?F to 122?F. Follow the care, sealing and operating instructions in the current manufacturer manual.
