Nocpix ACE S60R 2-24x Magnification 1280x1024 Sensor LRF Black Thermal Rifle Scope

Nocpix ACE S60R Thermal Scope – 1280x1024 | 60mm | LRF | 12x Ocular Zoom

The Nocpix ACE S60R is the flagship evolution of thermal weapon sights, pairing a 1280×1024 ultra-high-resolution thermal sensor with cutting-edge design and intuitive operation. Built to feel like a traditional day optic, the ACE S60R mounts with standard 30 mm rings and balances advanced imaging power with a streamlined aluminum alloy housing. It integrates a 1,300-yard laser rangefinder directly into the 60 mm germanium objective lens, aligning perfectly with the sight axis and minimizing bulk.

Inside, a crisp 2560×2560 AMOLED round display and ≤15 mK NETD thermal core produce remarkable image fidelity and contrast, even at long range. The 2× native magnification, 12× digital zoom, and 1–3× optical ocular magnifier provide seamless versatility across close, mid, and extended distances—ideal for professional users and serious hunters alike. Power options include an internal rechargeable pack, a removable 18650 battery, and USB-C external charging, allowing continuous field operation. Combined with a 5-year warranty, ballistic calculator, onboard recording, and app integration, the ACE S60R redefines what thermal precision optics can achieve.

Specifications

• Sensor Type: Nocpix 1280, 12 μm pixel pitch

• Sensor Resolution: 1280×1024

• Thermal Sensitivity: <15 mK

• Frame Rate: 50 Hz

• Display: 2560×2560 AMOLED (round), 1–3× optical magnifier

• Objective Lens: 60 mm f/1.0 Germanium

• Optical Magnification: 2× (base)

• Digital Magnification: Up to 12×

• Detection Range: 3,400 yards

• Rangefinder: Integrated 1,300-yard laser

• Power Options: Internal battery, 18650 cell, or USB-C external

• Battery Life: 6 + hours, hot-swappable

• Recording: Onboard photo/video with 64 GB storage

• Connectivity: Wi-Fi, USB-C data/power, mobile app

• Color Palettes: White Hot, Black Hot, Red Hot, Color, Violet, Crimson, Viridian

• Housing Material: Aluminum alloy, QD Picatinny mount

• Recoil Rating: 1000 g/s² (300 Win Mag / 7mm Mag rated)

• Environmental Rating: IP67, −4°F to 122°F

• Dimensions: 15.35" L × 3.54" W × 2.76" H

• Weight: 45.9 oz

• Warranty: 5 Years

Advanced imaging, intuitive controls, and a form factor ready for the field—this is the Nocpix ACE S60R.
