iRay Outdoor Hybrid Compact 3.5x 640x480 LRF 50mm Thermal Optic

The InfiRay Outdoor Hybrid Compact (HCH50R) is the next evolution in hybrid thermal technology, merging advanced imaging precision with unmatched versatility. Built for hunters, law enforcement, and long-range marksmen, this powerful device can serve as a dedicated thermal weapon sight, clip-on optic, or handheld monocular—all in one rugged package.

At its core lies InfiRay’s industry-first 10µm thermal sensor paired with a 50mm F/0.9 Germanium lens, delivering crystal-clear thermal definition even in near-total darkness. With a detection range exceeding 3,000 yards and a fast 60Hz refresh rate, targets appear lifelike and fluid through the vibrant 1440×1080 AMOLED display. The integrated 1,200-yard laser rangefinder and onboard ballistic calculator automatically adjust for range, ensuring precise shot placement with every pull of the trigger.

Engineered for real-world conditions, the HCH50R features magnesium alloy construction, IP67 weather protection, and recoil resistance rated up to .300 Win Mag. Capture every moment with built-in photo and video recording on 64GB of internal storage, and enjoy intuitive control via Bluetooth remote or mobile app. Whether mounted, clipped on, or handheld, the Hybrid Compact delivers professional-grade performance in a field-ready design.

Specifications:

• Device Technology: Thermal Imaging

• Sensor Resolution: 640×480 (10µm InfiRay MICRO II)

• Thermal Sensitivity: <15 mK NETD

• Frame Rate: 60Hz / 30Hz

• Objective Lens: 50mm F/0.9 Germanium

• Optical Magnification: 3.5X (8X digital)

• Detection Range: 3,060 yards

• Display: 1440×1080 AMOLED

• Eye Relief: 60mm

• Rangefinder: Integrated 1,200-yard LRF with Ballistic Calculator

• Recording: Onboard Photo & Video, 64GB Internal Storage

• Color Palettes: White Hot, Black Hot, Red Hot, Color, Violet, Crimson, Viridian

• Reticles: 8 (7 Static, 1 DIY)

• Power Source: 18650 Rechargeable Battery / USB-C External

• Battery Life: 7+ hours

• Mounting: DLOC Picatinny Mount

• Housing: Magnesium Alloy

• Protection: IP67 Waterproof / 1000 g/s² Recoil Rated

• Weight: 25.56 oz

• Dimensions (L×W×H): 9.87" × 4.05" × 3.07"

• Operating Temperature: -4°F to 122°F

• Warranty: 5 Years

Capture. Range. Engage. The InfiRay Hybrid Compact HCH50R redefines thermal performance—get yours at Battlehawk Armory!
